NIST SPECIAL PUBLICATION 1800-32A
Securing Distributed Energy Resources:
An Example of Industrial Internet of Things Cybersecurity
Volume A:
Executive Summary
Jim McCarthy
National Cybersecurity Center of Excellence
National Institute of Standards and Technology
Eileen Division
Don Faatz
Nik Urlaub
John Wiltberger
The MITRE Corporation
McLean, Virginia
February 2022
FINAL
This publication is available free of charge from https://doi.org/10.6028/NIST.SP.1800-32
Executive Summary¶
Protecting Industrial Internet of Things (IIoT) devices at the grid edge is arguably one of the more difficult tasks in cybersecurity. There is a wide variety of devices, many of which are deployed and operate in a highly specific manner. Their connectivity, the conduit through which they can become vulnerable, represents a growing cyber threat to the distribution grid. In this practice guide, the National Cybersecurity Center of Excellence (NCCoE) applies standards, best practices, and commercially available technology to protect the digital communication, data, and control of cyber-physical grid-edge devices. We demonstrate how to monitor and detect unusual behavior of connected IIoT devices and build a comprehensive audit trail of trusted IIoT data flows.
Challenge¶
The use of small-scale distributed energy resources (DERs), grid-edge devices such as solar photovoltaics, is growing rapidly and transforming the traditional power grid. As the use of DERs expands, the distribution grid is becoming a multisource grid of interconnected devices and systems driven by two-way data communication and power flows. These data and power flows often rely on IIoT technologies that are connected to wireless networks, given a level of digital intelligence that allows them to be monitored and tracked, and to share data on their status and communicate with other devices.
A distribution utility may need to remotely communicate with thousands of DERs, some of which may not even be owned or configured by the utility, to monitor the status of these devices and control the operating points. Many companies are not equipped to offer secure access to DERs and to monitor and trust the rapidly growing amount of data coming from them. Securing DER communications will be critical to maintaining the reliability of the distribution grid. Any attack that can deny, disrupt, or tamper with DER communications could prevent a utility from performing necessary control actions and could diminish grid resiliency.
This practice guide can help your organization: |
|---|
|
Solution¶
The NCCoE collaborated with stakeholders in the electricity sector, the University of Maryland, and cybersecurity technology providers to build an environment that represents a distribution utility interconnected with a campus DER microgrid. Within this ecosystem, we are exploring several scenarios in which information exchanges among DERs and electric distribution grid operations can be protected from certain cybersecurity compromises. The example solution demonstrates the following capabilities:
authentication and access control to ensure that only known, authorized systems can exchange information
communications and data integrity to ensure that information is not modified in transit
malware detection to monitor information exchanges and processing to identify potential malware infections
command register that maintains an independent, immutable record of information exchanges between distribution and DER operators
behavioral monitoring to detect deviations from operational norms
analysis and visualization processes to monitor data, identify anomalies, and alert operators
The example solution documented in the practice guide uses technologies and security capabilities (shown below) from our project collaborators. The solution is mapped to security standards and guidelines of the NIST Cybersecurity Framework; NIST Interagency or Internal Report 7628 Rev 1: Guidelines for Smart Grid Cybersecurity; and NIST SP 1108r4, Framework and Roadmap for Smart Grid Interoperability Standards, Release 4.0.
Collaboraor |
Security Capability or Component |
|---|---|
|
Offers long-term evolution infrastructure and communications on wireless broadband for campus DER microgrid communications |
|
Detects process anomalies or unwanted IIoT device modifications; provides identity and access management capabilities; controls access to resources |
|
Serves in an advisory role in smart grid and critical infrastructure cyber-physical security |
|
Provides operational technology network monitoring to detect malicious activity |
|
Affords data integrity and maintains a distributed ledger that gives an immutable audit trail for all data exchanges between the utility and the microgrid |
|
Offers cloud-based DER device log management and metrics that leverage big data analytics to produce real-time insights and actionable intelligence |
|
Manages privileged user permissions and access |
|
Delivers live data feed from on-campus solar arrays |
|
Allows multiparty, fine-grained policy creation, authentication, and secure access control and data sharing for human, machine, and application interactions across utility and DER operations |
While the NCCoE used a suite of commercial products to address this challenge, this guide does not endorse these particular products, nor does it guarantee compliance with any regulatory initiatives. Your organization’s information security experts should identify the products that will best integrate with your existing tools and information technology (IT) or operational technology (OT) system infrastructure. Your organization can adopt this solution or one that adheres to these guidelines in whole, or you can use this guide as a starting point for tailoring and implementing parts of a solution.
How to Use This Guide¶
Depending on your role in your organization, you might use this guide in different ways:
Business decision-makers, including chief information security, risk, compliance, and technology officers can use this part of the guide, NIST SP 1800-32a: Executive Summary, to understand the drivers for the guide, the cybersecurity challenge we address, our approach to solving this challenge, and how the solution could benefit your organization.
Technology, security, and privacy program managers who are concerned with how to identify, understand, assess, and mitigate risk can use NIST SP 1800-32b: Approach, Architecture, and Security Characteristics, which describes what we built and why, including the risk analysis performed and the security control mappings.
IT or OT professionals who want to implement an approach like this can use NIST SP 1800-32c: How-To Guides, which provide specific product installation, configuration, and integration instructions for building the example implementation, allowing you to replicate all or parts of this project.
Collaborators¶
Collaborators participating in this project submitted their capabilities in response to an open call in the Federal Register for all sources of relevant security capabilities from academia and industry (vendors and integrators). Those respondents with relevant capabilities or product components signed a Cooperative Research and Development Agreement (CRADA) to collaborate with NIST in a consortium to build this example solution.
Certain commercial entities, equipment, products, or materials may be identified by name or company logo or other insignia in order to acknowledge their participation in this collaboration or to describe an experimental procedure or concept adequately. Such identification is not intended to imply special status or relationship with NIST or recommendation or endorsement by NIST or NCCoE; neither is it intended to imply that the entities, equipment, products, or materials are necessarily the best available for the purpose.
